TECHNICAL INSTRUCTIONS FOR SAFETY RECALL 22TA06 POTENTIAL LOSS OF VEHICLE CONTROL CERTAIN 2023 MODEL YEAR bZ4X The repair quality of covered vehicles is extremely important to Toyota. All dealership technicians performing this repair are required to successfully complete the most current version of the E-Learning course “Safety Recall and Service Campaign Essentials”. To ensure that all vehicles have the repair performed correctly; technicians performing this repair are required to currently hold at least one of the following certification levels: • Expert Technician (Hybrid) Always check which technicians can perform the repair by logging on to https://www.uotdealerreports.com. It is the dealership’s responsibility to select technicians with the above certification level or greater to perform this repair. Carefully review your resources, the technician skill level, and ability before assigning technicians to this repair. It is important to consider technician days off and vacation schedules to ensure there are properly trained technicians available to perform this repair at all times. 1 I. OPERATION FLOW CHART The flow chart is for reference only. DO NOT use it in place of the full technical instructions. Follow ALL steps as outlined in the full technical instructions to confirm the campaign is completed correctly. No further action requiredNot CoveredCoveredCampaign complete.Return the vehicle to the customer.Verify Vehicle Eligibility1. Confirm vehicle VIN matches RO2. Check Vehicle Inquiry System for campaign eligibility Replace the axle hub bolts and wheels.Replace the Owner’s manual.All parts replaced as part of this Safety Recall will be recovered and must be turned over to the parts department. II. IDENTIFICATION OF AFFECTED VEHICLES 1. CHECK VEHICLE FOR CAMPAIGN ELIGIBILITY a) Compare the vehicles VIN to the VIN listed on the Repair Order to ensure they match. b) Check the TIS Vehicle Inquiry System to confirm the VIN is involved in this Campaign, and that it has not already been completed. NOTICE: TMNA warranty will not reimburse dealers for repairs completed on vehicles that are not affected or were previously completed, even by another dealer. 2 III. PREPARATION A. PARTS Part Number Part Description Quantity 04002-25142 WHEEL, DISC (18-inch) 4 Part Number Part Description Quantity 04002-25242 WHEEL, DISC (20-inch) 4 Part Number Part Description Quantity 04002-32142 BOLT, AXLE HUB* 1 * The kit above includes the following parts. Part Number Part Name Quantity 90942-02101 BOLT, HUB (FOR AXLE) 20 Part Number Part Description Quantity 90942-A5005 VALVE, TIRE PRESSURE MONITOR 4 Part Number Part Description Quantity – OWNER’S MANUAL* 1 *Owner’s Manual will be shipped directly to the dealer ATTN service manager for all confirmed vehicles at their location. B. TOOLS, SUPPLIES & EQUIPMENT • Standard Hand Tools • Torque Wrench • Tire Pressure Gauge • Car Tire Balancer • Tire Fitting Equipment • Torx Socket Wrench T10 SST – These are essential special service tools that the dealership should have. Part Number Part Description Quantity 09650-53010 One Touch Wheel Guide Pin 1 C. MATERIALS • Protective Gloves • Protective Glasses • Protective Tape • Marker • Soapy Water or Equivalent 3 IV. BACKGROUND After low-mileage use, all of the hub bolts on a wheel on the subject vehicles can loosen to the point where the wheel can detach from the vehicle. If a wheel detaches from the vehicle while driving, it could result in a loss of vehicle control, increasing the risk of a crash. No one should drive these vehicles until the remedy is performed. 4 V. COMPONENTS HINT: The illustration shown is LH front side of 18inch aluminum wheel specification. 5 VI. REPLACE WHEEL AND HUB BOLT 1. REMOVE THE WHEEL CAP (w/ 18 inch wheels) a) Remove the wheel cap. 2. RECORD THE TIRE MOUNTING POSITIONS a) Before removing the wheel and tire assembly from the vehicle, use tape marked with the wheel position on the vehicle. (e.g., right front =RF, right rear = RR, etc.). HINT: · If the TPMS is not installed in its original position, the pressure displayed on the multi-information display will not be displayed correctly. · In the unlikely event that the original position of the TPMS is no longer known, it is necessary to record the ID number of the tire pressure warning valve and transmitter and register it to the vehicle ECU. (For the procedure, refer to the repair manual.) 3. MARK THE OLD WHEELS • The new wheels and old wheels have the same shape and cannot be distinguished. • Be sure to mark the old wheels (surface of bolt holes) before removing the wheel assembly from the vehicle so that you can tell the new ones and old ones apart. • Make sure not to reinstall the old parts. a) As shown in the illustration, mark the wheel and middle of the axle hub bolt head (indented part) before removing the wheel assemblies from vehicle. For 20-inch aluminum wheels, DO NOT let paint contact the wheel cap or wheel hub ornament sub-assemblies since they are to be reused. 4. REMOVE THE TIRE w / WHEEL Refer to TIS for instructions on Suspension / TIRE / WHEEL / TIRE AND WHEEL / REMOVAL. HINT: Use SST or Wheel Guide Pin (0915B-53010) to facilitate alignment of wheel assembly with the axle hub bolt hole and to prevent the wheel assembly from falling. a) How to use the provided Wheel Guide Pin (1) Remove the axle hub bolt which is at the 12 o’clock position and install the wheel guide pin turning it clockwise by hand. (2) Remove the remaining 4 axle hub bolts, and remove the wheel assembly. 6 5. REMOVE WHEEL CAP SUB-ASSEMBLY AND WHEEL HUB ORNAMENT SUB-ASSEMBLY (w/ 20-inch wheels) a) Place a moving blanket or protective blanket on the work bench. b) Place the wheel face down so the back side of the wheel is exposed. c) Remove the wheel cap sub-assembly and the 5 wheel hub ornament sub-assemblies by releasing the claws on the backside of the wheel. Hint: Placing the wheel face down will prevent wheel hub ornaments from falling or dropping during removal. 6. REMOVE THE TIRE AND THE TIRE PRESSURE WARNING VALVE AND TRANSMITTER a) Remove the tires. Refer to TIS for instructions on Suspension / TIRE PRESSURE MONITORING / TIRE PRESSURE WARNING VALVE / REMOVAL. 7. INSTALL THE TIRE PRESSURE WARNING VALVE AND TRANSMITTER • Always use a NEW bolt, tubeless tire valve, valve core and tire valve cap when installing the tire pressure warning valve and transmitter. • Make sure not to damage the urethane covered backside of the tire pressure warning valve and transmitter (the surface opposite to the side with the ID code) with anything sharp. 8. INSTALL TIRE AND BALANCE WHEEL ASSEMBLY a) Reinstall the removed tires to the NEW wheels. Refer to TIS for instructions on Suspension / TIRE PRESSURE MONITORING / TIRE PRESSURE WARNING VALVE / INSTALLATION. HINT: The positions of the tire pressure warning valve and transmitter when they are set on the mounting machine are indicated in the repair manual, but they may differ with the recommended positions depending on the specifications of the mounting machine being used. Perform this work using the standard work methods that suit the equipment environment at the dealer so that the tire pressure warning valve and transmitter are not interfered with. 7 • When markings were forgotten, tires were rotated, etc., the “tire position write” procedure is necessary. Before installing the tires, write down the transmitter ID of the tire pressure warning valve and transmitter. • Check that there is no oil, water or lubricant around the rim hole, tire pressure warning valve and transmitter. Failing to do so may result in improper installation. • Use only a specified tire valve cap. If an unspecified tire valve cap is used, it may seize to the tire pressure warning valve and transmitter. • Make sure that the tire pressure warning valve and transmitter is installed so that the printed surface can be seen. If the tire pressure warning valve and transmitter is installed upside down, it may be damaged or fail to transmit signals when driving at high speeds. • Check that there is no deformation or damage to the tire pressure warning valve and transmitter. • Check that there is no foreign matter on the grommet and around the rim hole. • DO NOT apply soapy water or equivalent directly to the tire pressure warning valve and transmitter. • Make sure that the tire bead and mount tool DO NOT interfere with the tire pressure warning valve and transmitter. • Make sure that the tire pressure warning valve and transmitter is not clamped by the bead and rim. 9. INSTALL WHEEL CAP SUB-ASSEMBLY AND WHEEL HUB ORNAMENT SUB-ASSEMBLY (w/ 20 inch wheels) a) Install the wheel cap sub-assembly and 5 wheel hub ornament sub-assemblies that were removed from the old wheels. 8 10. HOW TO DISTINGUISH THE AXLE HUB BOLTS • The new axle hub bolt has a washer and an O-ring which keep the washer from falling off. • The bolt head flange has 3 ribs so that the new and old bolts can be distinguished even when they are installed on the wheels. • Check the difference between the new and old bolts to make sure the old bolts are not reinstalled. HINT: The length of the 3 ribs on the bolt head is slightly different depending on the manufacturer. a) Confirm the axle hub bolts are NEW ones. • If the vehicle was equipped with accessory locking hub bolts these will not be reused and will be recovered along with the old hub bolts. 9 b) CHECK AXLE HUB BOLT O-RING STATE (1) Check the O-rings for damage, deterioration (chips, scratches, cracks, fissures, fractures) and bite-in of foreign matter. Standard: There is no damage, deterioration and bite-in of foreign matter HINT: · If there is any foreign matter, clean and remove. · When cleaning, DO NOT disassemble the axle hub bolt or damage the O-ring. · If there is any damage or deterioration, replace the axle hub bolt with a new one. (2) Check the O-ring is properly installed. Standard: The O-ring is installed to the O-ring groove HINT: Ensure the O-ring is installed in the O-ring groove on the bolt as shown, if the O-ring is missing or damaged replace the axle hub bolt with a new one. 11. INSTALL THE TIRE w/ WHEEL Refer to TIS for instruction on Suspension / TIRE / WHEEL / TIRE AND WHEEL / INSTALLATION. Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf) • Check that there is no foreign matter or rust on the axle hub bolt hole threads and the contact surfaces of the wheel, brake disc, axle hub, etc. Clean the contact surfaces and axle hub bolts if necessary. If a wheel assembly is installed with foreign matter or rust between the contact surfaces, the foreign matter or rust may work loose. This may result in a reduction of the fastening force (axial force) leading to looseness or loss of one or more axle hub bolts. • When installing the axle hub bolts, check that the axle hub bolts rotate smoothly by hand. If the axle hub bolts do not rotate smoothly, check that there is no foreign matter or rust and clean if necessary. HINT: Use SST or Wheel Guide Pin (0915B-53010) to facilitate alignment of wheel assembly with the axle hub bolt hole and to prevent the wheel assembly from falling. 12. ADJUST THE TIRE AIR PRESSURE Adjust the tire air pressure after lowering the lift. If the pressure is adjusted while the vehicle is on the lift, and then the vehicle is lowered to the ground, the air pressure will change slightly due to a change in volume, and the meter display value may be offset. 10 a) Turn to READY On, and press the steering switch to display “Tire Pressure [kPa]” on the multi-information display. b) Adjust the tire inflation pressure to the specified value checking the values shown on tire pressure gauge and multi-information display. Cold Tire Inflation Pressure: 38 psi (260 kPa , 2.7 kgf/cm2,) HINT: If the tire inflation pressure is not displayed and “—” is shown, the transmitter may be damaged. Inspect the transmitter according to the repair manual. 13. REINSTALL THE WHEEL CAP (w/ 18 inch wheels) a) Align the position of the tubeless tire valve and wheel cap hole, and then install the wheel cap. Make sure to align the position of tubeless tire valve and wheel cap hole, otherwise the tubeless tire valve may be damaged. VII. REPLACE THE OWNER’S MANUAL 1. REPLACE OWNER’S MANUAL WITH UPDATED OWNER’S MANUAL a) Apply a mark to the recovered Owner’s Manual and then discard it. Example of Owner’s Manual HINT: Updated Owner’s Manual will have the following information Publication No. OM42G17U Part No. 01999-42G17 11 ◄ VERIFY REPAIR QUALITY ► – Confirm all hub bolts are torqued properly to: 140 N*m (1428 kgf*cm, 103 ft.*lbf) – Confirm the multi-information display can show the tire pressure for all four tires. – Confirm new Owner’s Manual is in the glove box. VIII. APPENDIX A. PARTS DISPOSAL As required by Federal Regulations, please make sure all recalled parts (original parts) removed from the vehicle are disposed of in a manner in which they will not be reused, unless requested for parts recovery return. B. CAMPAIGN DESIGNATION DECODER 2219 = 201920 = 202021 = 202122 = 202223 = 2023Etc…Year Campaignis Launched22TA01TT = ToyotaL = LexusVehicle MakeAA = Safety Recall RemedyB = Safety Recall InterimC = Special Service CampaignD = Limited Service CampaignE = Customer Support ProgramF = Emissions Recall(May use other characters in unique cases)Field Action Category and Phase0101 = 1st Field Action of the year02 = 2nd Field Action of the year03 = 3rd Field Action of the year(The sequence is unique for each Field Action category)(May use other characters in unique cases)Field Action Sequence Examples: 19TA01 = Launched in 2019, Toyota, Safety Recall Remedy Phase, 1st Safety Recall Launched in 2019 20TC02 = Launched in 2020, Special Service Campaign, 2nd Special Service Campaign Launched in 2020 21TE05 = Launched in 2021, Customer Support Program, 5th Customer Support Program Launched in 2021
