SAFETY RECALL 20LA01
VEHICLE MAY STALL DURING DRIVING AT HIGHER SPEED
2018 – 2019 GS 300
2013 – 2015 GS 350
2017 – 2019 GS 350
2018 – 2020 LC 500
2018 – 2020 LC 500h
2017 – 2020 RX 350
2018 – 2020 RX 350L
2014 – 2015 LX 570
2018 – 2019 LX 570
2017 IS 200t
2018 – 2019 IS 300
2014 – 2015 IS 350
2018 – 2019 IS 350
2018 – 2020 ES 350
2013 – 2015 LS 460
2017 GS 200t
2019 UX 200
2014 – 2015 GX 460
2018 – 2019 GX 460
2017 RC 200t
2018 – 2019 RC 300
2015 RC 350
2018 – 2019 RC 350
2018 – 2020 LS 500
2018 – 2019 LS 500h
2018 – 2019 NX 300
2015 NX 200t
2014 IS-F
The remedy for this campaign is being launched in phases. Confirm remedy eligibility on each VIN in TIS before starting any repairs.
Update 7/1/2021: Technician qualifications to perform this recall have been updated
Update 3/31/2021: 2018 – 2019 GX 460 models added
Update 3/25/2021: 2019 NX 300 model added
Update 3/18/2021: 2018- 2019 LX 570 models added
Update 2/25/2021: 2018 NX 300; 2020 RX 350 / RX 450L added
Update 2/18/2021: 2019 UX 200 model added
Update 2/10/2021: Instructions added for use of Retainer Ring Pilers
Update 2/10/2021: Tips added for Removal, Disassembly and Reassembly
Update 1/13/2021: 2017 GS 200t, GS350; 2020 ES 350, LS 500, LC 500 and LC 500h models added
Update 10/22/2020: LX 570 has been added
Update 6/26/2020: NX 200t, 2013-2015 GS 350, 2014-2015 IS 350,2015 RC 350,
2013-2015 LS 460 models have been added
Update 6/16/2020: GX, ES (US built), RX models have been added
Update 5/22/2020: LS, LC & IS-F models have been added
Update 5/6/2020: Details of the NEW Cam Lock style campaign tool have been added
BACKGROUND
The subject vehicles are equipped with a low-pressure fuel pump which may stop operating. If this were to occur, warning lights and messages may be displayed on the instrument panel, and the engine may run rough. This may result in a vehicle stall, and the vehicle may be unable to be restarted. If a vehicle stall occurs while driving at higher speeds, this could increase the risk of a crash.
SAFETY PRECAUTIONS
CAUTION:
When installing/uninstalling the fuel system components, keep safety first in mind and carefully observe the following instructions to avoid accidents:
When working on the fuel system, display a Flammable – Keep Fire Away sign.
Smoking is prohibited nearby.
Perform this work in an area where there are no sparks nearby from the operation of welders, grinders, drills, electric motors, stoves, etc.
DO NOT use electrical devices nearby because they can become hot and the operation of power switches can generate sparks.
DO NOT use iron or steel hammers while working, because they may generate sparks.
DO NOT start engines even in adjacent stalls.
Prepare fire extinguishers before starting any work.
Perform this work in a well-ventilated area (natural ventilation). DO NOT use exhaust fans or electric fans, because their motors might generate sparks.
Since it is possible for fuel vapor to build up, DO NOT work in or near a pit.
If fuel is spilled, use shop towels or similar material to quickly wipe it up and then use compressed air to diffuse the fuel vapor.
Shop towels and other materials that have come into contact with fuel should be dried in a well ventilated area and then disposed of as appropriate.
SAFETY RECALL 20LA01 – Vehicle May Stall During Driving at Higher Speed – 2013-2020 Lexus
SAFETY RECALL 20LA01 – Vehicle May Stall During Driving at Higher Speed – 2013-2020 Lexus
Remedy Instructions and TSB
