TECHNICAL INSTRUCTIONS
FOR
SAFETY RECALL 20TA16
POTENTIAL FUEL TANK LEAK
CERTAIN 2020-2021 SUPRA
Update 05/04/21
- Instructions for ordering the fuel tank SST have been revised
PARTS
Part Number | Part Description | Quantity | Remarks |
77001-WAA01 | Fuel Tank Sub-assy | 1 | |
77169-WAA01 | Fuel Suction Tube Set Gasket | 1 | |
41204-WAA01 | Nut (for Drive Pinion Companion Flange Rear) | 1 | |
90118-WA203 | Bolt (for Flexible Coupling) | 3 | ENGINE MODEL: B58 |
90118-WA834 | ENGINE MODEL; B48 | ||
90118-WA699 | No.2 Nut (for Propeller Shaft & Differential Setting) | 3 | ENGINE MODEL: B58 |
90118-WA205 | ENGINE MODEL; B48 | ||
90118-WA387 | Exhaust Pipe Clamp | 1 | ENGINE MODEL: B58 |
90118-WA472 | ENGINE MODEL; B48 | ||
90118-WA264 | Nut | 1 | |
90118-WA063 | Nut | 5 | |
77651-WAA01 | Fuel Tank Cushion No.1 | 10 |
SAFETY RECALL 20TA16 – Potential Fuel Tank Leak – 2020-2021 Toyota Supra
SAFETY RECALL 20TA16 – Potential Fuel Tank Leak – 2020-2021 Toyota Supra
Remedy Instructions and TSB
Update 05/04/21
RCRIT-20V700-3257.pdf 3690.973KB
Remedy Instructions and TSB – POTENTIAL FUEL TANK LEAK CERTAIN 2020-2021 SUPRA
RCRIT-20V700-9369.pdf 3685.878KB
Latest Recalls Documents
For the Latest and Most Recent Recalls Information Visit the link below…
https://www-odi.nhtsa.dot.gov/acms/cs/documentList.xhtml?docId=20V700&docType=RCL
